ApparelX is a global B2B marketplace for fabrics and apparel materials.

›
NSW100

NSW100 Water-soluble Resin Interlining For Product Dyeing And Product Washing Soft Type 40/[Interfacing] Nittobo Advantex

NSW100

Water-soluble Resin Interlining For Product Dyeing And Product Washing Soft Type 40/

Name: Water-soluble Resin Interlining For Product Dyeing And Product Washing Soft Type 40/
Brand: Nittobo Advantex
SKU: 1020000
Rating: 5 (2 reviews)

ApparelX ID:1020000

Because it is made of 100% cotton, it can be dyed in the same color as the outer material when dyed with direct dyes.
Since we use a water-soluble adhesive resin, it is glued during the sewing stage, but when washed with water it becomes a non fusible interlining, giving it a comfortable texture that cannot be achieved with fusible interlining.
It uses a dot-type resin structure, so it is less sticky and easier to handle than conventional sintered types.

Brand / Manufacturer:Nittobo Advantex

Supplier:

Color:Please select

Stock Status(*):Displayed after account registration

*Excl. tax

Qty.

Ask About This Product

Color

Please select a color:

Order Remarks

Add a note for the supplier or for your own reference:

Enter Order Remarks

Order Sample Book

Order a sample book here:

*Note: Sample Book Item will be added to your cart. Remove it from your cart if you do not need it. Your order notes will also be applied to the sample book.

SAMPLE

Sample Card

Product Description

Press conditions ・ Flat type

temperature	120 ~ 135 ℃
time	10 to 15 seconds
pressure	2.0 ~ 3.0 × 10-² MPa (0.2 ~ 0.3kgf / cm²)

・ Roller type

temperature	120-135 ℃
time	10-12 seconds
pressure	0.15 ~ 0.3MPa (1.5 ~ 3.0kgf / cm²)

* Press conditions vary depending on the press model, so it is recommended to try and paste each time.

<Caution>
-The adhesive may become viscous in a humid place. Please keep away from hot and humid places.
・ When cutting, roll in one direction.
-When using, please process the core retainer such as stitches and locks.
・ Do not dry clean the product while it is still adhered.
-When dyeing or washing the product, first dissolve the resin in water at 40 ° C or lower, and then perform the drainage and rinsing process.

product number	ONW30	ONW50	BW810	BW820	BW870	BW890	NSW30	NSW100	NSW190W	NSW300	NSW600
Product name	Highly durable interlining for bio products (30D)	Highly durable interlining for bio products (50D)	Product washing process Water-based washable durable interlining (15D)	Product washing processing, water-based washing durable interlining (30D)	Product washing processing, water-based washable durable interlining (30D)	Product washing processing, water-based washable durable interlining (30D)	Water-soluble resin interlining for product dyeing and washing, stretch-processed thread type	Water-soluble resin interlining for product dyeing and washing, soft type 40/	Water-soluble resin interlining for product dyeing and washing, standard type 45/	Water-soluble resin interlining for product dyeing and washing, hard type	Water-soluble resin interlining for product dyeing and washing, semi-hard type 45/
Thumbnail
Order of thickness	2	3	1	2	2	2	2	3	3	5	4
type	Highly durable, fully adhesive type	Highly durable, fully adhesive type	Highly durable, fully adhesive type	Highly durable, fully adhesive type	Highly durable, fully adhesive type	Highly durable, fully adhesive type	Water-soluble type/stretch	Water-soluble type/soft	Water-soluble type/standard	Water-soluble type/Hard	Water-soluble type/semi-hard
Applications	Jackets, blousons, coats	Jackets, blousons, coats	Blouson, jacket, coat, pants front, facing, parts	Blouson, jacket, coat, pants front, facing, parts	Blouson, jacket, coat, pants front, facing, parts	Blouson, jacket, coat, pants front, facing, parts	General product washing, shirts, etc.	General product washing, shirts, etc.	General product washing, shirts, etc.	General product washing, shirts, etc.	General product washing, shirts, etc.
Suitable materials	Natural materials, composites, synthetic materials	Natural materials, composites, synthetic materials	Natural materials, composites, synthetic materials	Natural materials, composites, synthetic materials	Natural materials, composites, synthetic materials	Natural materials, composites, synthetic materials	Natural to composite materials	Natural to composite materials	Natural to composite materials	Natural to composite materials	Natural to composite materials

*You can scroll horizontally.

*The above information is for reference only. Please check the actual product before use.

Category	Interfacing
Subcategory	Fusible Interlining
Gender	Unisex
Intended Use	General Purpose
Weave	Taffeta
Style	PANT, SHIRT, SKIRT


Specification	88/92 cm width x 60 meters
Material	100% cotton CO
Brand / Manufacturer	Nittobo Advantex

Share This Item

FAQ

Frequently asked questions about this product:

What are the standard sizes for inside belt interfacing used in men's garments?

33 mm, 38 mm.

What kind of problem is kiratsuki?

It is the phenomenon of resin sparkling through the gaps in the weave of the face fabric.
Materials with a loose weave and dark-colored lightweight fabrics are especially noticeable, so using colored resin will resolve it.

What kind of problem is bleed-through?

A state where adhesive resin seeps through to the outer fabric, impairing the fabric’s hand.
As a solution, choose one with a smaller adhesive resin particle size.

What does the D (denier) in 20D or 30D mean?

Denier is a unit used for filament yarn (continuous filament fiber)*, indicating the weight per 9,000 m. If 9,000 m weighs 1 g, it is 1 denier; if it weighs 50 g, it is 50 denier.
The higher the denier count, the thicker the thread and the heavier the fabric.

What kind of problem is bubbling?

A condition where fine air bubbles appear to be trapped between the outer fabric and interlining. It occurs because the compatibility between the fabric and interlining is poor. It may be resolved by choosing an interlining with vertical and horizontal stretch.

What kind of problem is fading?

It is when the uneven texture of the resin pellets becomes clearly visible on the surface of the outer textile. The solution is to choose interfacing with smaller resin dots.

What is the difference between single-dot and double-dot fusible interlining?

It is a difference in the adhesive coating method.
Single dot is made by solidifying fine powdered adhesive and transferring it in a dotted pattern onto the base fabric.
Because the adhesive is fine, it is less likely to bleed through thin materials and less likely to cause fading.
Double dot has a two-layer structure, with a gel-like adhesive forming the base and powdered adhesive layered on top of it.
It provides strong adhesion for a wide range of materials.

What is the difference between the whites such as KW, OW, W, and Y in fusible interlining colors?

The color notation varies by product number, but KW and W are fluorescent white, and Y and OW are off-white.
Fluorescent white is a whiter, purer white.

Can interfacing be shipped rolled on a tube?

Basically, orders of 5 m or more will be shipped wound on a tube.

How should I choose interfacing?

The appropriate interlining varies depending on the face fabric material, thickness, and area of use, so we cannot give a single answer.
Please contact us via inquiries with the face fabric material, area of use (neckline, body, etc.), and desired hand feel.

If you can provide the face fabric, we can perform an adhesion test. Please request this from Interlining Adhesion Test.
By performing an adhesion test, you can find out in advance things like adhesive strength and changes in appearance.

General Notes

Please confirm the following general notes regarding items at this site:

Zipper | Payment when you choose 'Fast Delivery'

If we cut a longer zipper to the length you want, the price will be changed.

Please make a payment after the price is fixed, in the case of Bank Transfer.

*** In the case of Credit Card, we will charge the extra after the price is fixed.

Product image disclaimer

Product images may not accurately represent actual colors. For bulk production, confirm the color using a physical sample.

Payment for Full-Roll Fabric Orders

The exact length of a full fabric roll may vary. We will notify you once the final length is confirmed.

*** For bank transfers, please pay after the final length is confirmed.

*** For credit card payments, any additional amount will be charged after the final length is confirmed.

Need help? Visit our Support page

Reliable: 75 Years in the Industry

MOQ: From 1 Meter, 1 Piece, 1 Set

Flexible Shipping Option: DHL, EMS, etc.

Credit Cards / Wallets / On Account

Reviews

See reviews from other customers.

Share your experience by posting a review.

hiro

Purchased at ApparelX

Safe for post-dyeing

Aug 10, 2023

Color:Y

Used for piece-dyed products.
Even if it is dyed together with bleached textile, it can be dyed equally or more deeply.
Once washed, it will be in a fluffy state, so it seems that it can be used for delicate textile.

Details:

Design

Functionality

Thickness

Size

Color

Durability

Reasonability

Handling

1 found this helpful

K.T.

Purchased at ApparelX

For piece-dying shirts

Aug 28, 2020

Color:Y

I'm always planning to dye products, so I was looking for something water-soluble. With regular interlining, some dyes would have an effect, but with this product, there was no effect at all. I'm saved.

Details:

Functionality

7 found this helpful
