This item is discontinued and cannot be purchased. For the successor item code, see the Item Description or Related Items section.
See available products with similar photos
R8501
Danrene Interlining Standard For Thin Water-Repellent Coated Materials, Resin Fading Prevention SDDC
ApparelX ID:1021414
There are no reviews yet.
A special resin is used, which provides high adhesion to thin, water-repellent coated materials that are difficult to adhere to. SDDC is a Nittobo technology that uses ultrafine particles for high-performance adhesives. By using fine resin, it prevents bleeding, resin fading, and glare even on thin surfaces, and achieves high adhesive strength.
Please select a extension key: (Note: The colors in the images are not the actual colors. The actual color usually depends on the color you select.)
Review the estimated production completion date below. This date may change.
Depending on the order quantity, we may be unable to supply the full amount requested.
As a general rule, orders cannot be canceled once procurement arrangements are complete.
If a production issue occurs, delivery may be delayed. You may cancel the order in this case.
Size
Color
Production Status
Estimated Completion Date
*Last updated:
Stock Status
Stock levels change frequently. Contact us if you need confirmed availability.
Products shipped from the brand or manufacturer's warehouse may require additional delivery time.
If an item is found to be out of stock after you place your order, we will cancel the order and issue a refund.
If stock is insufficient, procurement and delivery may take several months.
Review the estimated delivery date above before ordering.
Color
Stock Location
Available Quantity
30 Black
Own warehouse
4m
Y
Own warehouse
57m
*Last updated:Oct 20, 2026, 18:38
Order Memo
Add a note for the supplier or for your own reference:
Option
You can select options below:
Order Sample Book
Order a sample book here:
*Note: The sample book below will be added to your cart. If you do not need it, remove it on the Cart page. Its memo is pre-filled with the item code and name from this page.
Currently, the sample book is out of stock. For details, please contact us through our support page.
Item Description
A special resin is used, which provides high adhesion to thin, water-repellent coated materials that are difficult to adhere to. SDDC is a Nittobo technology that uses ultrafine particles for high-performance adhesives. By using fine resin, it prevents bleeding, resin fading, and glare even on thin surfaces, and achieves high adhesive strength.
Press conditions ・ Flat type
temperature
130 ℃ ~ 150 ℃
time
10 to 15 seconds
pressure
2.0-3.0x10-²MPa (0.2-0.3kgf / cm²)
・ Roller type
temperature
120 ℃ ～ 140 ℃
time
10-12 seconds
pressure
0.15-0.3MPa (1.5-3.0kgf / cm²)
* Press conditions vary depending on the press model, so it is recommended to try and paste each time.
What are the standard sizes for inside belt interfacing used in men's garments?
33 mm, 38 mm.
What kind of problem is kiratsuki?
It is the phenomenon of resin sparkling through the gaps in the weave of the face fabric. Materials with a loose weave and dark-colored lightweight fabrics are especially noticeable, so using colored resin will resolve it.
What kind of problem is bleed-through?
A state where adhesive resin seeps through to the outer fabric, impairing the fabric’s hand. As a solution, choose one with a smaller adhesive resin particle size.
What does the D (denier) in 20D or 30D mean?
Denier is a unit used for filament yarn (continuous filament)* and refers to the weight per 9,000 m. If 9,000 m weighs 1 g, that is 1 denier; if it weighs 50 g, that is 50 denier. The higher the denier count, the thicker the yarn and the heavier the fabric.
What kind of problem is bubbling?
A condition where fine air bubbles appear to be trapped between the outer fabric and interlining. It occurs because the compatibility between the fabric and interlining is poor. It may be resolved by choosing an interlining with vertical and horizontal stretch.
What kind of problem is fading?
It is when the uneven texture of the resin pellets becomes clearly visible on the surface of the outer fabric. The solution is to choose interfacing with smaller resin dots.
What is the difference between single-dot and double-dot fusible interlining?
It is a difference in the adhesive coating method. Single dot is made by solidifying fine powdered adhesive and transferring it in a dotted pattern onto the base fabric. Because the adhesive is fine, it is less likely to bleed through thin materials and less likely to cause fading. Double dot has a two-layer structure, with a gel-like adhesive forming the base and powdered adhesive layered on top of it. It provides strong adhesion for a wide range of materials.
What is the difference between the whites such as KW, OW, W, and Y in fusible interlining colors?
The color notation varies by product number, but KW and W are fluorescent white, and Y and OW are off-white. Fluorescent white is a whiter, purer white.
How should I choose interfacing?
The appropriate interlining varies depending on the face fabric material, thickness, and area of use, so we cannot give a single answer. Please contact us via inquiries with the face fabric material, area of use (neckline, body, etc.), and desired hand feel.
If you can provide the face fabric, we can perform an adhesion test. Please request this from Interlining Adhesion Test. By performing an adhesion test, you can find out in advance things like adhesive strength and changes in appearance.
Can interfacing be shipped rolled on a tube?
Basically, orders of 5 m or more will be shipped wound on a tube.
